Load Cell SLP333D-IOL-500kg C6/6k
Single Point Load Cell for Automation with IO-Link interface SLP333D-RTU 500kg C6
Material No.: 30786471
Highlights
Integrated PLC connectivity
The SLP33xD-IOL load cells connect directly to any automation systems via IO-Link, no additional electronic unit is needed.
Quick installation
Standard cables and connectors reduce complexity for installation. Accurate factory calibration allows immediate startup.
Smart5™ alarms and condition monitoring
With continuous condition monitoring and alarms according to NAMUR NE 107 higher machine uptime and increased productivity achieved.
Specifications
Specifications - Load Cell SLP333D-IOL-500kg C6/6k
| Connectivity | Integrated |
| Maximum Capacity | 1,100 lb (500 kg) |
| Metrology | NTEP III 10,000d OIML C6 |
| Protection Rating | IP67 |
| Material | Aluminum, passivated |
| Platform Size (LxW) | 600 mm x 600 mm |
