Material No.: 2821286400
| IP Rating | IP65 IP69 |
| Compatible Software | TraceServer |
| Connectivity | Ethernet OPC UA USB |
| Inspection Solution | X-ray Inspection |
| Max Product Width | 439 mm |
| HMI | 15" Touchscreen |
| Packaging Type | Bags Cardboard Cartons Composite Cans Glass Metal Cans Metalized Film Plastic Trays VFFS |
| Cooling Method | Air Conditioner |
| Product Flow | Conveyorised |
| X-ray Beams | Single vertical beam |
| Max Product Length | 1,600 mm |
| X-ray Generator | 100 W, up to 84 kV, up to 1.2 mA Glass Tube 140 W up to 140 kV, up to 1.0 mA Glass Tube 420 W, up to 84 kV, up to 5.0 mA Beryllium Tube 420 W, up to 84 kV, up to 5.0 mA Glass Tube 490 W up to 140 kV, up to 3.0 mA Glass Tube |
| Inspection Application | Clip Detection Completeness Check Fill level Check Foreign Body Detection Integrity Check Mass Control Product-Trapped in Seal |
| Product Characteristic | Deep Frozen Round Container Small Individual Wrapped Products Small-Medium Packages Thawing |
| Industry | Chemical Food & Beverage Pharma & Biotech |
| Max Product Height | 215 mm |
| Industry Segment | Bakery and Confectionary Beer, Wine and Other Alcoholic Beverages Bulk Chemicals Cosmetics Dairy Fine and specialty chemicals Food Additives Meat & Poultry & Seafood Nutraceuticals Oils and Fats Pet Food and Animal Feed Pharma Ready Meals Snack Foods Sugar Starch and Yeast Water and other Non-Alcoholic Beverages |
| X-ray Detector | Dual Energy, MDX Technology Dual Energy, PXT Technology Single Energy, HiQiQ Technology |
| Max Product Weight | 68 kg |
| X-ray Emissions | < 1uSv/hr |
| Max Line Speed | 120 m/min |
| Max Throughput | 123 ppm PXT |
| Diode Size | 0.4 mm 0.8 mm 1.2 mm |
