Software Facilitates Operator Control
Proprietary software enables operators to effortlessly program semi-automated product set-ups with minimal training required, ensuring uptime.
Maximizes Production Space Efficiency
Available at 800 or 1800mm system lengths, the X33 requires less line space to accommodate production planning constraints wherein space is a premium.
Sustainable Low Energy Solution
Powered by a 20W generator, the X33 is a low energy inspection solution delivering reduced Total Cost of Ownership.
Material No.: 30468718
| Brand Protection
|Outstanding sensitivity of metal, glass, mineral stone, calcified bone and high density rubbers
|Support FSMA and all GFSI codes including BRC & IFS
| Ease of Use
|High performance x-ray software can reduce the need for manual adjustments and the potential for human programming errors
| Increased Productivity
|World class reliability and OEE reporting
| Conveyor Speed (dependent on product dimensions)
|10 - 60 m/min
| X-ray Detector Width and Diode Size
|300mm or 400mm - 0.8mm diode size
| Personal Care
| Number of Lanes
| X-ray Generator
|20W (84kV, 0.25mA Glass Tube)
| X-ray Beams
|Single vertical beam
| X-ray Emissions
| Reject Type
|Pusher or airblast, lift flap or retracting belt options
| Cooling Method
|Passive fan assisted internal cooling
| Operating Temperature
|5 °C - 40 °C
| Power Supply
| 100 - 120 Vac, 1 phase, 50-60 Hz, 10 A max
208 - 240 Vac, 1 phase, 50-60 Hz, 6 A max
|10.1” LED Touchscreen display (16:9 aspect ratio)
| IP rating
| IP65 as Standard
| Packaging Material
| Aluminium Foil
| Throughput Rate (dependent on product dimensions)
|Up to 300 ppm
Cooling Solution Saves Operational Costs
An internal fan instead of an external air conditioning unit cools the X33, reducing maintenance time and Total Cost of Ownership.
Proves Due Diligence
All inspection activities are monitored and recorded in real-time to avoid product recalls and, if needed, demonstrate due diligence.
Optimum Detection at Reduced Power
The X33 uses only 1/5th of the power needed by traditional x-ray systems to achieve high levels of detection sensitivity.
5 Year Generator Warranty
Minimize your downtime and protect the most valuable and expensive part of your inspection system, the x-ray generator, for 5 years when you purchase it with a Standard or Comprehensive Care Package.
Global Presence, Local Support
A global network of service experts provide fast remote and on-site support. Our comprehensive service offering allows you to achieve regulatory compliance, high performance, and maximum uptime throughout the life cycle of your product inspection equipment.
Enhancing Production Data Visibility
Ensure the highest levels of regulatory compliance through real-time data collection. ProdX, our PC-based software, constantly monitors and fully documents all production parameters, quality incidents, user interactions and performance verification routines.
