The high resolution weighing cell delivers fast and accurate results. Together with the StatusLight™, you get reliable results, every time.
Efficient Touchscreen Operation
The touchscreen interface, easy-access menus, results notepad, and saved weighing methods make balance operation instinctive and efficient.
Reliable performance, ergonomic weighing processes, and easy data transfer ensure you get the accurate results you want, quickly and efficiently.
Material No.: 30317518
Available for purchase
| Maximum Capacity||8.1 kg|
| Readability||0.1 g|
| Repeatability, typical||40 mg|
| Settling Time||1 s|
| Adjustment||Internal (automatic/FACT)|
| Interfaces|| USB-B (to device)|
USB-A (to device)
| Display||4.5" color TFT touchscreen|
| User management||Password protection|
| Legal for Trade||Yes|
| Weighing Pan Size ( DxW) or Diameter||190.00 mm x 223.00 mm|
| Minimum Weight (USP, 0.1%, typical)||82 g|
| Linearity ±||100 mg|
| Repeatability||80 mg|
| Weighing Pan Dimensions (WxD)||190 mm x 223 mm|
| Dimensions (HxWxD)||99 mm x 194 mm x 391 mm|
| Terminal size||4.5 inch|
| Compliance Options|| Data Integrity|
Log history (21 CFR Part 11 Compliant)
Log history (Basic Metadata)
| Balance Line||XSR|
| Balance Type||Precision Balance|
| Capacity||8,100 g|
| Balance Size (Depth)||391 mm|
| Balance Size (Width)||94 mm|
| Preferred model||Performance|
| Documentation Options|| Printing|
Basic Electronic Documentation
Automatic Documentation (21 CFR Part 11 Compliant)
| Balance Size (Height)||99 mm|
| Guaranteed Repeatability||80 mg|
| 21 CFR Part 11 Compliant Weighing||Yes|
| Readability (Certified)||1 g|
| Automation Options||Automated Workflows|
| Material Number(s)||30317518|
Secure Data Handling with LabX
LabX® software automatically captures results, performs all calculations, and saves all data in a secure database, providing a high level of process security and full traceability. Customized reports can be generated at any time.
Save balance filter settings, process settings, and tolerances on the balance as individual methods. Easily accessed, methods offer a quick and convenient way to start tasks; every user follows the same procedures and results are always within tolerance.
StatusLight uses color to provide instant information on the balance status. Green means it's safe to weigh and results will be valid, yellow is a warning, perhaps that a routine test is due, and red means an issue must be resolved before weighing.
Placing the display at eye-level on the adjustable ErgoStand™ saves space and eliminates excessive bending of the neck. Optional remote switches simplify workflows, reduce process steps, and leave your hands free to handle samples and equipment.
Safe and Easy Cleaning
The supplied covers protect the terminal and housing and are easily replaced when soiled. The balance body resists harsh chemicals, whilst smooth surfaces and rounded edges make it easy to clean.
Benefit From Our Weighing Know-How
Our free GWP® Recommendation ensures you have the right balance for your weighing process. With years of weighing expertise, we can support you with balance selection, installation, cleaning, routine testing, calibration and maintenance.
Comprehensive Service Offering
Our services include installation and qualification, calibration, maintenance, and routine testing to ensure your balance is fit for purpose and meets industry standards and regulatory requirements. Customize your service package to meet your precise needs.
