Compact Scale ICS435s-3SM/f/M/65

Reliable Performance.

Strain Gauge Technology

ICS435, the basic weighing level solution, is optimized for quick and easy weighing applications. It features a numeric keypad for quick pretaring.

Durable and Rugged

Tough enough for use in industrial environments with aluminum die cast housing, overload protection and robust foil keypad.

Dust-Proof with Guaranteed Accuracy

This dust-proof system is legal for trade, and its accuracy is guaranteed by a nationally accredited facility prior to shipment.

Specifications - Compact Scale ICS435s-3SM/f/M/65
Maximum Capacity
3 kg
Readability (Certified)
0.5 g
Repeatability (sd)
0.03 g
Platform Size (Length)
200 mm (7.9 in)
Platform Size (Width)
240 mm (9.5 in)
Platform Size (Height)
95 mm (3.7 in)
Material
Aluminium diecast
Protection Rating
IP65
Repeatability
0.05 g
Hazardous Approval
No
Housing
Aluminum Diecast
Interfaces
RS232
Display
Graphic LCD with backlit
Repeatability (typical)
0.03 g
Application Software
Dynamic Weighing; Simple weighing
Legal for Trade
OIML
Data Interface
Serial; USB; Ethernet; WLAN
Applications
Simple Weighing; Dynamic weighing
Environment
Dusty & Light Wet (IP65)
Hazardous Area
Non-hazardous area
Voltage
Battery Version; AC Version
Scale Interface
SICSpro
Interfaces (Optional)
USB; Ethernet; RS422; RS485; WLAN; Discrete I/O
Hygenic Design
No
Performance Optimization
MinWeigh: Minimum Weigh determination acc. your tolerance limits; Easy Scale Leveling: For fast & precise leveling; High Resolution: Special aluminum strain gauge load cell
Process Integration
Variety of Interfaces: For easy process integration; 1 Standard & 1 Optional Interface: Serial, USB, Ethernet, WLAN, Dig. I/O; Control Additional Platforms: 1 platform attachable
Data Management
Convenient Printing: Easy creation of print & label templates; Custom Print Formats: Odette, AIAG, Galia etc.
Compliance Support
Intuitive User Guidance: Prevents from operator errors
Versatility
Mobile Operation: Battery optional available; Good Readability: Graphic LCD-Display with backlit; Numeric Keypad: For fast operation; Versatile Scale: For demanding weighing tasks in dry environment
Platform Type
Compact Scale
Legal for Trade Class OIML
Class III
Zero Return (typical)
0.04 g
Error of Indication at half load (typical)
0.15 g
Hysteresis (typical)
0.05 g
Eccentric Load Deviation at 1/3 of Full Load (typical) (Metric)
0.25 g
Error of Indication at full load (typical)
0.08 g
EasyPrint Name
ICS435s-3SM/f/M/67
Material Number(s)
22023105
