Weighing Platform PBA429-QB15

For Demanding Applications.

High Durability

The rugged, full stainless steel frame & the hermetically sealed load cell ensures a long life time also when used in harsh, wet & humid environments (IP68/IP69k).

Easy to Clean

The open and sturdy platform design is built according to hygienic standards and allows fast, thorough and easy cleaning.

Hygienic Design

To easily reduce on site-contamination, this platform features a hygienic-kit, containing specially designed leveling kits and overload stops.

Specifications - Weighing Platform PBA429-QB15
Maximum Capacity
15 kg (25 lb)
Readability
1 g (0.002 lb)
Repeatability(sd)
0.4 g (0.0009 lb)
Platform Size (Length)
305 mm (12 in)
Platform Size (Width)
305 mm (12 in)
Platform Size (Height)
108 mm (4.25 in)
Material
Stainless Steel V2A (AISI 304)
Protection Rating
IP69k; IP68
Hazardous Approval
No
Scale Interface
Analog
Readability (Certified)
5 g (0.005 lb)
Repeatability
1 g
Repeatability
0.002 lb
Repeatability (typical)
0.4 g
Repeatability (typical)
0.0009 lb
Weighing Pan Dimensions (Length)
305 mm (12 in)
Weighing Pan Dimensions (Width)
305 mm (12 in)
Weighing Pan Dimensions (Height)
57 mm (2.24 in)
Dimensions (Length)
305 mm (12 in)
Dimensions (Width)
305 mm (12 in)
Dimensions (Height)
108 mm (4.25 in)
New Attribute (2)
3 m (9.9 ft)
Legal for Trade
NTEP; OIML
Environment
Wet & Harsh Wet (>/=IP66)
Dimensions/Platform Size
</=400 mm; from 6.3" to 15.7"
Hazardous Area
Non-hazardous area
Linearity, typically
5 g
Linearity
5 g (0.005 lb)
Linearity (typical)
0.005 lb
Hygenic Design
No
Performance Optimization
For Harsh Wet Environments: Hermetically sealed stainless steel load cell
Compliance Support
Hygienic Designed: Easy to Clean
Versatility
Weighing Platform: For versatile weighing tasks harsh wet environment
Maximum Capacity (AM metric)
10 kg
Platform Type
Bench Platforms
Legal for Trade Class OIML
Class III
Legal for Trade Class NTEP
Class III
Readability (Certified) (AM metric)
2 g
Zero Return (typical)
0.5 g (0.0011 lb)
Error of Indication at half load (typical)
1 g (0.0022 lb)
Hysteresis (typical)
0.7 g (0.0016 lb)
Eccentric Load Deviation at 1/3 of Full Load (typical) (Metric)
2.3 g
Eccentric Load Deviation at 1/3 of Full Load (typical)
0.0051 lb
Error of Indication at full load (typical)
0.9 g (0.002 lb)
EasyPrint Name
PBA429-QB15H
Material Number(s)
72229526
