pH Sensor InPro4262/225/PT1000
The InPro 4262 is an analog, in-line pH probe with hydrofluoric acid resistant glass for demanding chemical applications.
Material No.: 52003552
Highlights
Specifications
Specifications - pH Sensor InPro4262/225/PT1000
| ISM (Digital) or Analog | Analog |
| pH Sensing Technology | Hydrofluoric Acid Resistant Glass Membrane (HF) |
| pH Range | 1 – 14 |
| Reference System | Xerolyt Extra polymer electrolyte, open double junction, Argenthal cartridge with silver-ion trap |
| Operating Temperature (Fahrenheit) | 32 °F - 266 °F |
| Operating Temperature (Celsius) | 0 °C - 130 °C |
| Cable Connector | VP |
| Process Connection | Pg 13.5 Thread |
| Sterilizable/Autoclavable | No |
| Sensor Length | 225 mm |
| Certificates & Approvals | ATEX/IECEx: Ex ia IIC T6/T5/T4/T3 Ga/Gb CE FM: IS Cl. I, II, III, Div 1, GR ABCDEFG/T6 METTLER TOLEDO Quality Certificate PED |
| Operating Pressure (Bar) | 0 to 15 barg @ 25°C 0 to 7 barg @ 130°C |
| Model Family | InPro4260(i) |
| Temperature Sensor | PT 1000 |
| Measurement Parameter | pH |
| Shaft Material | Glass |
| Operating Pressure (PSI) | 0 to 101 psig @ 266°F 0 to 217 psig @ 77°F |
| Refillable Electrolyte | No |
| Hazardous Area Approvals | Yes |
| Primary Media/Application | Chemical Processes |
| Hygienic/Biocompatibility Approvals | No |
Documentation
Certificates
Accessories
Consumables
Buffers for In-Line pH Sensors
Technical Buffer pH 2.00 6x250ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This package contains six bottles of 250mL of pH 2.00 buffer solution.
Material No.: 51319010
Technical Buffer pH 2.00 1000ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single bottle contains 1000 mL of pH 2.00 buffer solution.
Material No.: 51319011
Technical Buffer pH 4.01 6x250ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This package contains six bottles of 250mL of pH 4.01 buffer solution.
Material No.: 51340058
Technical Buffer pH 4.01 1000ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single bottle contains 1000 mL of pH 4.01 buffer solution.
Material No.: 51340228
Technical Buffer pH 7.00 6x250ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This package contains six bottles of 250mL of pH 7.00 buffer solution.
Material No.: 51340060
Technical Buffer pH 7.00 1000ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single bottle contains 1000 mL of pH 7.00 buffer solution.
Material No.: 51340229
Technical Buffer pH 9.21 6x250ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This package contains six bottles of 250mL of pH 9.21 buffer solution.
Material No.: 51300194
Technical Buffer pH 9.21 1000ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single bottle contains 1000 mL of pH 9.21 buffer solution.
Material No.: 51340230
Technical Buffer pH 10.00 6x250ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This package contains six bottles of 250mL of pH 10.00 buffer solution.
Material No.: 51340231
Technical Buffer pH 10.00 1000ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single bottle contains 1000 mL of pH 10.00 buffer solution.
Material No.: 51340232
Buffer pH 4.01 ACS red 5000ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single container holds 5000 mL of pH 4.01 buffer solution.
Material No.: 51319012
Buffer pH 7.00 ACS green 5000ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single container holds 5000 mL of pH 7.00 buffer solution.
Material No.: 51319016
Buffer pH 9.21 ACS blue 5000ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single container holds 5000 mL of pH 9.21 buffer solution.
Material No.: 51319017
Technical Buffer pH 2.00 250ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single bottle contains 250 mL of pH 2.00 buffer solution.
Material No.: 51340055
Technical Buffer pH 4.01 250ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single bottle contains 250 mL of pH 4.01 buffer solution.
Material No.: 51340057
Technical Buffer pH 7.00 250ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single bottle contains 250 mL of pH 7.00 buffer solution.
Material No.: 51340059
Technical Buffer pH 9.21 250ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single bottle contains 250 mL of pH 9.21 buffer solution.
Material No.: 51300193
Technical Buffer pH 10.00 250ml
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single bottle contains 250 mL of pH 10.00 buffer solution.
Material No.: 51340056
